A drop in for the 40W halogen recessed lights. Recessed 3.5” LED light 2700K 85CRI Dimmable COB LED
Lower profile design then other halogen and LED offerings
Excellent Viewing Angle: 120 degrees
Eplex compatible: works with most dimmers without additional electronics
Details
Elegant white trim with frosted glass make this light the perfect choice. Three screw mounting compatible with the most popular models and a tapered back to allow for wire storage. Digitally dimmable design means you will not need additional circuitry to adjust to just the right output. Warm White, Warm White/Red and Warm White/Blue available. Two or Three wire configurations. Simply reverse polarity to switch between colors or hi/lo.
Designed with Lunasea’s robust electronics and temperature monitoring these lights were designed for minimal interference with electronic equipment. Can be dimmed externally.
Soft 2700K warm white hi CRI COB LED light enhances the beauty of your surroundings.
Technical Information
Warm White / Red
Voltage
10-40VDC MAX
Power Consumption
3.75 Watt
Light Output
375 Lumens
Color Temp
2700K, 85+ CRI
LED
3.75 Watt CREE LED
Beam Angle
120 degree - Fixed
Dimmable
Yes
Mounting
Three screw mounting compatible with the most popular models and a tapered back to allow for wire storage.
Measurements
3.5 inch
Enclosure
White Trim
Wire Length
8 Inches
Warranty
2 Year
Your new LLB-46WW-2A-xx light has the capability of being remotely dimmed by the following:
Use any digital dimming switch or EPLEXTM controller you choose (NOT INCLUDED)- 100% dimming capability
Reversing the polarity (2 wire setup) - HI/LO capability or White/Red(Blue)
Using three wire setup apply power to either of the + leads - HI/LO or White/Red(Blue) capability
