The F30 Series of linear LED fixtures were designed as an LED replacement for the popular Resolux 700 Series low voltage fluorescent fixtures. They deliver higher lumen output and with greater efficiency than their fluorescent predecessors. Choose from four sizes (15" through 49" lengths). Models come in either 12VDC or 24VDC, with or without a switch, and any of them may be dimmed using common PWM digital dimmers such as the Imtra Intervolt dimmer combined with a remote single throw momentary switch. Depending on the application, you may choose from traditional "warm-white" illumination or a cool-white. Some models are even available with switchable warm/cool output.
LED replacement for Resolux 700 Series fluorescent
A+ Energy Efficiency rating (EU-Directive 87412012)
Dimming compatibility with most halogen PWM digital dimmers
Rear or surface-mount cabling
Wide beam illumination
UV stable PC lens will not yellow over time
Maintenance free: No bulbs to change or store
Name
Description
Beam Angle Certifications & Compliance Class Color Rendering Index (CRI) Correlated Color Temperature (CCT) Dimensions Dimmer Compatibility Dimmer Control Interface Dimming Range Driver Efficiency Electrical Protections Halogen Equivalency Housing Finish/Material Ingress Protection Input Voltage Install Location Integrated Switch Lens Material Lifetime Hours Luminous Flux Manufacturer Mounting Method Output Color Power Consumption
108 dg CE, ROHS III 85 6000K 384 mm/15.12 in x 85mm/3.35 in x 22mm/0.87 in PWM Digital Dimmers (e.g. Intervolt) N/O, Single Throw Momentary 1 Integrated 0.75 Reverse Polarity, Transients 35W Annodized aluminum/UV stable PC IP40 24VDC Surface-mount, dry location No PC 30000 600 Frensch Screw-mount (ss fasteners included) Cool White 8W
